Drive Protection FeaturesAnti-roll away braking and alarm, Antistall motor protection, Regenerative braking, Diagnostic indicator, Full torque with reduced speed reverse.
ELECTRICAL SYSTEM
Power Source48volt 8*6V T-105 batteries
FRAME
Frame TypeMIG welded uni-body, high strength steel
Standard Utility FeaturesBattery discharge indicator, reverse warning indicator, operator presence switch, hour meter, headlight switch, two cup holders, glove box.
Product Gallery
Frequently Asked Questions
What is the maximum speed and range of this electric UTV?
The vehicle features a maximum forward speed of 0-24kph and a reverse speed of 0-15kph. It is capable of achieving an endurance range of up to 150km under optimal operating conditions.
How long does it take to charge the battery system?
The system utilizes 8*6V batteries and a ferroresonant transformer charger. A full recharge is estimated to take between 8 to 12 hours under a standard 240VAC +/- 10% input at 50HZ.
What are the weight and dimensions of the vehicle?
This UTV measures 2750mm in length, 1750mm in width, and 1185mm in height, with a wheelbase of 1860mm. It has a dry weight of 685kg and a maximum laden weight of 1340kg.
What safety features are integrated into the drive system?
The drive system is equipped with an anti-roll away braking system and alarm, antistall motor protection, regenerative braking, diagnostic indicator, and a full torque feature with reduced speed reverse.
What braking system is installed on this vehicle?
The UTV is engineered with a hybrid braking configuration, utilizing high-performance disc brakes on the front wheels, reliable drum brakes on the rear wheels, and a mechanical parking brake.
What certifications does this electric utility vehicle hold?
This electric vehicle model is fully certified under CCC, EEC, and CE standards, ensuring compliance with international safety and quality regulations.
