Kabar Golf
1 / 5
| Parameter | Details | |
|---|---|---|
| Basic Specification | ||
| Overall dimensions | 3100mm*1200mm*1850mm | |
| Quality of service | 470KGS | |
| Min ground clearance | 330mm | |
| Wheelbase | 2450mm | |
| Allowable load | 550KGS (4 people) | |
| Max Speed | ≤40km/h | |
| Climb ability | 20% (≈11°) | |
| Body & Structure | ||
| Frame | High strength carbon steel integral frame, phosphating electrophoretic rust prevention | |
| Body Material | PP injection molding, automotive color baking process with UV components | |
| Roof | Injection molding ceiling | |
| Windshield | Foldable | |
| Seat | Artificial leather, Waterproof cushion | |
| Electric System | ||
| Battery (Standard) | Maintenance-free Battery, 48V150Ah | |
| Battery (Optional) | 48V/72V Lithium Iron phosphate options (105Ah - 180Ah) | |
| Motor | 5kW Three asynchronous AC motors (Standard) / 7.5kW (Optional) | |
| Controller | Inpower-3528 350A (Standard) / Curtis (Optional) | |
| Display | 10.1 inch LCD screen: Bluetooth, Radio, Carplay, Reverse image | |
| Chassis | ||
| Front Suspension | Front double A arm independent suspension | |
| Brake System | Foot pedal four wheel hydraulic disc brake | |
| Tires | 22*10 -14 off-road tires | |
| Rim | 14-inch aluminum rims classic shape | |
Our company is a vehicle manufacturer specializing in personalized customization and refitting. The company has a strong background in automotive and all-terrain vehicle design technology, and broad ideas for new product development. We have rich supply chain resources and are good at cross-border integration to truly achieve the industry's most cost-effective products and the most professional services.
The price of our electric low-speed vehicles ranges from US$2,000 to US$7,000. With rich OEM experience and ODM capabilities, partial or complete vehicle customization can be realized. As a manufacturer that constantly develops new products, we are always at the forefront of the industry. We successfully launched off-road style appearances and real 4-wheel drive systems, making our products more capable in various terrains.
Our factory believes in the business philosophy of "independent research and development, leading technology, first-class service, and integrity-based". We have launched a series of electric special vehicles and obtained several patents. The products are exported to more than 30 countries on five continents around the world, and have won unanimous praise.
