| Parameter | Specification Details | |||
|---|---|---|---|---|
| Motor | 4.0KW AC Motor | |||
| Controller | 60V Fully intelligent controller | |||
| Battery | 48V150Ah | |||
| Charger | Vehicle-mounted smart charger | |||
| Charging time | 8-10 hours (discharge rate is 90%) | |||
| Charging input voltage | 220V (Customizable according to requirements) | |||
| Maximum driving speed | 30km/h | |||
| Maximum Climbing slope | 30 degree | |||
| Minimum turning radius | 2.5m | |||
| L*W*H | 2800*1250 *1950mm | |||
| Wheelbase | 980mm | |||
| Wheel distance (front and rear) | 900mm/ 1000mm | |||
| Braking distance | <5m | |||
| Minimum ground distance | 150mm | |||
| Driving mileage | 90-110km | |||
| Rated number of passengers | 4 people | |||
| Vehicle weight | 470kg | |||
| Power transmission system | Continuously variable speed system | |||
| Front axe and suspension | MacPherson independent suspension | |||
| Rear axle and suspension | Integrated rear axle/ High-strength steel plate spring/ Cylindrical damping | |||
| Braking system | Drum hydraulic brake/ Cual circuit hydraulic brake/ Parking brake device | |||
| Wheel | 20"10.00-12 0ff-raad tires/ Aluminum alloy wheel hub | |||
