This 2+2 golf cart utilizes lithium-ion battery technology, offering outstanding energy efficiency and environmental friendliness. Integrating advanced technologies such as off-road tires and WiFi connectivity, its compact and stylish design combines aesthetics with performance. Primarily serving senior living communities, it provides a superior travel experience for families and tourists. Equipped with luxurious seats for ultimate comfort, it enjoys a strong reputation and a stable customer base in the Canadian market. The vehicle boasts excellent safety features, high comfort, long range, and convenient and efficient charging. Suitable for various occasions, it offers exceptional value for money, supports wholesale and retail business, and provides a comprehensive after-sales service system, ensuring customer peace of mind.
| Category | Configuration Parameter | 2+2 seats non lifted |
|---|---|---|
| Vehicle Parameters | Length*width*height (mm) | 2910*1150*1865 |
| Wheel base (mm) | 1700 | |
| Front/rear wheel track (mm) | 985/1025 | |
| Front/rear suspension (mm) | 245/459 | |
| Min. Ground Clearance (full load) (mm) | ≥180 | |
| Minimum turning radius (m) | ≤4m | |
| Curb weight (kg) | 490 | |
| Person capacity (qty) | 4 | |
| Rated load (kg) | 320 | |
| Total mass (kg) | 810 | |
| Maximum speed (km/h) | 32/40 | |
| Range on a single charge (km) | 70-90 | |
| Power System | Motor type | AC MOTOR |
| Rated power (Kw) | 5KW / 7.5KW | |
| Maximum power (Kw) | 12 | |
| Voltage (V) | 48-72 | |
| Battery capacity (KWh/AH) | 5.376-11.04 | |
| Battery type | Lithium iron phosphate / Lead acid | |
| Standard Recharge Time (hours) | 8 | |
| Suspension & Wheels | Front/rear suspension | McPherson / Trailing arm |
| Front/rear tyre model | 12-inch road tires or 14-inch off-road tires | |
| Brake & Steering | Front/rear brake type | Disc brake |
| Parking brake type | EBRAKE / 55N.m | |
| Steering gear type | Rack and pinion | |
| Power-assisted steering | ○ | |
| Basic Configuration | Wireless charging | ○ |
| Sound Dominator | ○ | |
| USB interface | ● | |
| Multimedia Large-Screen Panel | ● | |
| Bluetooth handsfree | ● |
| Category | Configuration Parameter | 2+2 seats non lifted |
|---|---|---|
| Vehicle Parameters | Length*width*height (in) | 114.6*45.3*73.4 |
| Wheel base (in) | 66.9 | |
| Front/rear wheel track (in) | 38.8/40.4 | |
| Front/rear suspension (in) | 9.6/18.1 | |
| Min. Ground Clearance (full load) (in) | ≥7.1 | |
| Minimum turning radius (ft) | ≤13.1 | |
| Curb weight (lb) | 1080 | |
| Person capacity (qty) | 4 | |
| Rated load (lb) | 705 | |
| Total mass (lb) | 1786 | |
| Range on a single charge (mile) | 43-56 | |
| Power System | Driving form | Solid rear axle |
| Motor type | AC MOTOR | |
| Rated power (hp) | 6.7/10.1 | |
| Maximum power (hp) | 16.1 | |
| Peak torque of the motor (lb·ft) | 48/88 | |
| Voltage (V) | 48-72 |
